ScottoWing PCB Kit

Please note that a case is required for this board.

This is a PCB kit for the ScottoWing (PCB Edition) keyboard. It's an excellent board for a beginner as it uses very easy-to-solder components.

Features:

• All 1U keys for easy keycap sourcing
• Fully hotswap with Kailh sockets
• South-facing switches for Cherry compatibility
• 4x5 (34-keys) or 4x6 (40-keys)
• DO-35 through-hole diodes for easy soldering
• nice!nano (ZMK) or RP2040 Pro Micro (QMK)
• Vial support (wired only)
• Battery power switch (nice!nano)
• JST battery connector (nice!nano)
• Physical reset button on the back (nice!nano)

The kit includes the following:

• PCB
• 40 through-hole diodes
• 40 Kailh MX hotswap sockets
• 1 Power switch
• 1 Button
• 1 JST-PH connector
• 2 1x12 Female Sockets

You will need the following to complete the build:

• 34 or 40 MX switches
• 34 or 40 1u keycaps
• 1 RP2040 Pro Micro or nice!nano
• 1 3D printed case

Since I release all my handwired boards for free I do not release any files for my PCB boards other than firmware. Please be aware that the only way to get a 3D printed case is by purchasing one through me, thank you for understanding.

Firmware

You can find the firmware files on the qmk_firmware repository or you can compile them online using the QMK Configurator. You can also download pre-compiled firmware here.
